Name: Terminal Folk Lug
Code: 115-9
Description:

Detailed Information of Furcate Pre-Insulating terminal

Material

Copper

Plating

Tin

Thickness

Thickness: 0.7mm,0.8mm,1.0mm

Insulation
PVC

Color
Red, Yellow, Black,Grey, and other customized color

Working Temp

-40 to +105°C

Cable Range

A.W.G.:22-16 (0.5-1.5mm²),16-14(1.5-2.5mm²), 14-12(2.5-4mm²), 12-10(4-6mm²)

MOQ

Small orders accepted

Payment Term

A.L/C,T/T (Bank Transfer, Wire Transfer)

B.Western Union

C.Paypal (For samples fee & Courier cost)

Terms of Payment: FOB Shanghai / Ningbo;CIF;CNF;etc

Delivery Time

A.By Courier: 4-7 Working days by special offer

B.By Air: 7 Working days at appointed airport

C.By Sea: 20-25 Working days at appointed port

Supply Ability

2 x 20 feet containers per week

Packaging Details

A.Common Packing:100pcs + polybag + label + inner box+ export carton

B.Customized Packing:OEM Label,Inner Box,Blister,etc

HS Code

8536900000

Origin Country

Zhejiang, China

Test Report

REACH, ROHS.

Data Sheet of Furcate Pre-Insulating terminal

Cable size;0.5~1.5mm²(A.W.G.22~16)    max current;Imax=19A

material;purple copper    thickness;0.75mm

CODE USA screw screw dia.d2(mm) Dimension(mm) color

B L F H Dφ

(115-9-1) SV 1.25-3 #4 3.2 5.7 21.2 6.5 10 4.3 red

(115-9-2) SVS 1.25-3.5 #6 3.7 5.7 21.2 6.5

(115-9-3) SVL 1.25-3.5 #6 3.7 6.4 21.2 6.5

(115-9-4) SVS 1.25-4 #8 4.3 6.4 21.2 6.5

(115-9-5) SVM 1.25-4 #8 4.3 7.2 21.2 6.5

(115-9-6) SVL 1.25-4 #8 4.3 8.1 21.2 6.5

(115-9-7) SVS 1.25-5 #10 5.3 8.1 21.2 6.5

(115-9-8) SVL 1.25-5 #10 5.3 9.5 21.2 6.5

(115-9-10) SVS 1.25-6 1\4 6.4 9.5 21.2 6.5

(115-9-11) SVL 1.25-6 1\4 6.4 12 27.2 11

Cable size;1.5~2.5mm²(A.W.G.16~14)    max current;Imax=27A     material;purple copper    thickness;0.8mm

(115-9-12) SV 2-3 #4 3.2 5.7 21.2 6.5 10 4.9 blue

(115-9-13) SVS 2-3.5 #6 3.7 5.7 21.2 6.5

(115-9-14) SVL 2-3.5 #6 3.7 6 21.2 6.5

(115-9-15) SVS 2-4 #8 4.3 6.4 21.2 6.5

(115-9-16) SVM 2-4 #8 4.3 7.2 21.2 6.5

(115-9-17) SVL 2-4 #8 4.3 8.1 21.2 6.5

(115-9-18) SVS 2-5 #10 5.3 8.1 21.2 6.5

(115-9-19) SVL 2-5 #10 5.3 9.5 21.2 6.5

(115-9-20) SVS 2-6 1\4 6.4 9.5 21.2 6.5

(115-9-21) SVL 2-6 1\4 6.4 12 27.2 11

Cable size;2.5~4mm²(A.W.G.14~12)    max current;Imax=37A     material;purple copper    thickness;1.0mm

(115-9-22) SV 3.5-3 #4 3.2 5.7 24.8 7 13 6.2 black

(115-9-23) SV 3.5-4 #8 4.3 8 24.8 7

(115-9-24) SV 3.5-5 #10 5.3 8 24.8 7

(115-9-25) SV 3.5-6 1\4 6.4 12 28 12.1

(115-9-26) SV 3.5-8 5\16 8.4 12 33.7 13.7

Cable size;4~6mm²(A.W.G.12~10)    max current;Imax=48A     material;purple copper    thickness;1.0mm

(115-9-27) SV 5.5-3.5 #6 3.7 8.3 2.2 7.5 13 6.7 yellow

(115-9-28) SVS 5.5-4 #8 4.3 8.3 25.2 7.5

(115-9-29) SVL 5.5-4 #8 4.3 9 25.2 7.5

(115-9-30) SV 5.5-5 #10 5.3 9 25.2 7.5

(115-9-31) SVS 5.5-6 1\4 6.4 9 25.2 7.5

(115-9-32) SVL 5.5-6 1\4 6.4 12 31.2 12

(115-9-33) SV 5.5-8 5\16 8.4 14 30 11.5
